Using a wine bottle cap with an RFID chip, when consumers unscrew the wine bottle cap, the label chip and the antenna on the bottle cap are broken, and the RFID tag becomes invalid immediately.
Wine bottle cap RFID electronic label features:
1. Smart and convenient, stable and reliable, easy to use.
2. Diversity of expressions.
Application scope of RFID electronic label for wine bottle cap:
RFID electronic tags have the characteristics of global uniqueness, non-copying, anti-transfer, automatic identification and other functions. The chip code in the electronic label is unique, and the secret control information, including product information, can be entered through the electronic label. It can realize the functions of anti-smuggling and traceability. The coding of information is added in the production process, and various information such as the production date, raw materials, shelf life, origin, alcohol concentration and even which production line of the wine can be edited and coded, so as to realize the production, sales and use links. Verification, when the wine reaches the retail terminal market, the retail customer can use the retail terminal information system to identify and parse the code on the product package, read the wine factory information and retail customer order information, and after it is circulated to the consumer, the consumer can use the mobile phone. By querying the platform, you can obtain the wine's circulation channel information and authenticity identification services.
As shown in the picture above, a wine bottle cap with an RFID chip is used. When consumers unscrew the wine bottle cap, the label chip and the antenna on the bottle cap are broken, and the RFID label becomes invalid immediately. This label is different from the traditional RFID easy-to-use label. The broken wine label ensures that the outside of the label is well protected from damage during use. After tearing off, the surface paper and the antenna can be separated, and cannot be imitated, which solves the problem of the label being recycled and reused. It can also be made in the form of a tag, and the chip is embedded in the tag; it can also be combined on the packaging of the wine bottle, such as the decorative stickers on the wine bottle and the outer packaging such as combined in the wine box, etc. The expression can be based on the wine. Customized packaging design.
Wine bottle cap RFID electronic label label parameters:
Specification size 40mm×20mm (can be customized according to customer needs)
Protocol EPC C1G2 (ISO-18000-6c)
Chip H3 (LF, HF, UHF chips can be packaged according to customer requirements)
Operating frequency 860～960MHz
Recognition distance 5~6cm in the air, 2~3cm on the wine box (aluminum foil)
